Incoloy 800HT｜Alloy 800HT｜N08811｜Pipe and Tube
Incoloy 800HT （Alloy800HT，UNS08811） is a fully austenitic low-carbon nickel iron chromium alloy of the same series as Incoloy 800, and the cobalt content in this alloy can be strictly controlled below 0.01%.
The alloy can withstand corrosion from many corrosive media. Its high nickel content makes it have good resistance to stress corrosion cracking under water-based corrosion conditions. The high chromium content gives it better resistance to spot corrosion and crevice corrosion cracking. This alloy has good resistance to nitric acid and organic acid corrosion, but its corrosion resistance is limited in sulfuric acid and hydrochloric acid. Besides the possibility of point corrosion in halides, it has good corrosion resistance in both oxidizing and non oxidizing salts. It also has good corrosion resistance in mixtures of water, steam, steam, air, and carbon dioxide.
Product Description
1. Chemical composition of Incoloy 800HT
| Chemical Composition（wt. %） | ||||||||||
| Brands No. | UNS | C | Cr | Ni | Ti | Fe | Mn | Si | Cu | Al |
| Incoloy 800HT | N08811 | 0.05%~ 0.1% | 19%~ 23% | 30%~ 35% | 0.15%~ 0.6% | Balance | ≤1.5% | ≤1.0% | ≤0.75% | 0.15%~0.6% |
2. Physical Properties of Incoloy 800HT
| Physical properties | Mechanical Properties & Others | ||||||
| Brands No. | Density g/cm3 | Melting point | Yield Strength | Tensile Strength Mpa | Elongation A5 % | Hardness HRB | |
| /℃ | Rp0.2(MPa) | Rp1.0(Mpa) | |||||
| Inconel 800HT | 8.00 | 1350~1400 | 500 | 210 | 35% | ≤200 | |
3. Product Implementation Standards of Incoloy 800HT
| Trademark* | Material | UNS | W.Nr. | Density | Tube | Pipe |
| smls/wld | smls/wld | |||||
| Incoloy 800HT | Alloy 800HT | N08811 | 1.4876 | 8.00 | B163/B515 | B407/– |
4. Specifications Available for Pipes and Tubes of Incoloy 800HT :
- Seamless Tube: OD6-630 WT0.3-100mm
- Capillary: OD0.2-6 WT0.02-2mm
- Welded Pipe: on demand.
5. Applications of Incoloy 800HT
- Boiler components in petrochemical and chemical industries
- Heat exchange devices in high temperature and corrosive environments
- Steam generators in power plants
- Carburizing fixtures and crucibles in industrial furnaces
- Heating element jackets
- Ammonia coolers
6. Contact Us for More Information of Nickel Alloy Pipes and Tubes
As a Professional Nickel Alloy & Stainless Steel Pipes and Tubes Exporter, Southerly Special Alloy was founded in Dec-2021.Our core members have more than 5 years experience in Nickel Alloy and Stainless Steel manufacturing and related fields.We serve customers worldwide, our main markets are in Europe, Middle East, South East Asia, South America and Africa.
Please fill out the form below or send an email to sales@southerly-alloy.com for more information.
